50W Rigid Solar Panel (R50)

Compact 50W rigid solar panel designed for light-duty fleet, vehicle, and fixed off-grid power applications.

SHORT DESCRIPTION

The MOENERGY R50 is a compact and durable 50W rigid solar panel engineered for light-duty vehicle, fleet, and stationary installations. Its rigid glass construction and MC4-compatible output make it ideal for battery maintenance and low-power off-grid systems.

KEY FEATURES

• 50W monocrystalline solar panel for low-power applications

• Rigid tempered glass with anodized aluminum frame

• MC4-compatible output connectors

• Compact footprint for space-constrained installations

• Weather-resistant construction for outdoor use


TECHNICAL SPECIFICATIONS

• Rated Power (Pmax): 50W

• Cell Type: Monocrystalline

• Number of Cells: 30 (3 × 10)

• Module Efficiency: 20%

• Maximum Power Voltage (Vmp): 17.2V

• Maximum Power Current (Imp): 3.20A

• Open Circuit Voltage (Voc): 20.64V

• Short Circuit Current (Isc): 3.36A

• Maximum System Voltage: 1000V DC

• Max Series Fuse Rating: 10A

• Operating Temperature: -40°C to 85°C

• Power Tolerance: ±3%


MECHANICAL SPECIFICATIONS

• Panel Type: Rigid

• Dimensions: 23.42 × 20.27 × 1.18 in (595 × 515 × 30 mm)

• Weight: 7.72 lb (3.5 kg)

• Front Glass: 3.2 mm tempered glass

• Frame: Anodized aluminum (silver)

• Junction Box Rating: IP65

• Cable Length: 35.4 in (900 mm)

• Connector Type: MC4 compatible


CERTIFICATIONS & COMPLIANCE

• FCC

• CE

• RoHS


TYPICAL APPLICATIONS

• Vehicle battery maintenance

• Fleet tracking and monitoring equipment

• RVs, trailers, and small campers

• Small fixed off-grid systems

• Backup power for low-load devices
