Glass Solar Panel Platform (Baseline)
Glass Solar Panel Platform (Baseline)
Not sure if this is the right panel?
Standard Rigid Glass Solar Panels for OEM, Fleet, and Scalable Programs
MOENERGY’s glass solar panel platform represents the baseline architecture for rigid photovoltaic modules. Built with monocrystalline cells, tempered front glass, and an anodized aluminum frame, this platform offers a proven balance of efficiency, durability, cost, and broad compatibility across OEM, fleet, and industrial deployments.
Why Glass Solar Panels
- Proven and widely adopted rigid panel architecture
- Good balance of cost, durability, and electrical performance
- Compatible with standard mounting rails and brackets
- Well-suited as a baseline reference for OEM and fleet programs
Platform Example: 100W Glass Solar Panel
The 100W glass panel serves as the reference configuration for this platform and anchors comparisons with aluminum-backed and flexible solar platforms.
Key electrical characteristics:
- Rated power (Pmax): 100 W
- Maximum power voltage (Vmp): 17.2 V
- Maximum power current (Imp): 5.8 A
- Open circuit voltage (Voc): 20.4 V
- Short circuit current (Isc): 6.6 A
- Module efficiency: 22%
- Power tolerance: ±3%
Mechanical and environmental features:
- Monocrystalline cells (182 × 182 mm)
- 30 cells (3 × 10 layout)
- Dimensions: 960 × 580 × 30 mm (37.8 × 22.8 × 1.2 in)
- Weight: 6.2 kg (13.7 lbs)
- 3.2 mm tempered front glass
- Anodized aluminum frame
- IP65 junction box with MC4 connectors
- Operating temperature: –30°C to 95°C
- Maximum system voltage: 1000 V DC
Scalability & Customization Options
- Multiple wattage configurations and cell counts
- Connector and cable variations (MC4, SAE, custom harnesses)
- Private labeling and documentation customization
- Program-specific compliance (FCC, CE, RoHS)
- Packaging and palletization optimized for volume programs
Intended Applications
- Standard vehicle and RV solar installations
- Fleet and bulk deployments
- Industrial and enclosure-mounted systems
- OEM programs requiring a conventional rigid panel baseline
Site Placement Reference
This glass solar panel platform should be presented as the baseline platform within:
It provides the reference point for comparison against:
Note on Solar Kits
Solar charging kits (panels bundled with controllers, brackets, and accessories) are treated as deployment configurations rather than standalone scalable product platforms. At this stage, MOENERGY does not present kits as a separate scalable platform, as kits are assembled programmatically based on application and customer requirements
